Advantech Leo-D IoT ePaper Solution

LEO-D ePaper Sub-1 GHz

Centralised Management of ePaper Deployment

Advantech ePaper infrastructure is centrally managed and updated through the LEO-D Device Manager. The integrated back-end system can remotely transmit and receive data to and from the respective ePaper device. By providing a visual interface, the monitoring of power, online/offline status, layout management, content preview - as well as maintenance, and scheduling, the LEO-D Device Manager delivers the flexibility to design and set up your very own customised user case.

Value and Highlights

  • Sub-1GHz technology enables long-range data transmissions for rapid updates.
  • Ultra-low power consumption provides long battery life (up to 20,000 changes).
  • Low maintenance & Hardware cost
  • Wireless and compact design ensures rapid installation within 3 seconds.
  • Flexible display fastener with diverse mount methods (lock with screws, stick/paste).
  • Rugged design with IP54-rated protection against water and dust ingress.
  • Sunlight-readable display with 180-degree viewing angle.
  • Strong Propagation/High Penetration Rate (for example 40m through 3 concrete walls).
  • Flexible tag pairing for any workstation through Roaming.
  • Block-locating with received signal strength indication techniques to wirelessly determine asset location.

Product Specs

  • LEO-D30 - 2.90" ePaper NFC (batteryless) - black / white
  • LEO-D30 NFC Reader
  • LEO-D31 - 2.90" ePaper - black / white / red, up to 20,000 times update
  • LEO-D51 - 5.65" ePaper - black / white / red, up to 8,000 times update
  • LEO-D81 - 11.60" ePaper - black / white / red, up to 5,000 times update
  • 868/915MHz Gateway for LEO-D, support up to 15 Sub-G Hubs
  • 868/915MHz Hub for LEO-D, supports upt to 1,000 LEO-D devices
  • LEO Server
  • LEO Device Manager S, supports up to 20 Gateways

LEO-D ePaper BLE 5.0

LEO-D BLE 5.0 are ePaper displays that represents a new generation of environmentally friendly products. Designed to replace printed paper, the LEO-D ePaper displays are a low-power information display solution equipped with BLE 5.0 communication that allows the display content to be synchronously updated. The embedded BLE 5.0 protocol offers excellent signal penetration for long-range transmissions . Moreover, with its minimal power consumption, the LEO-D BLE ePaper displays are ideal for IoT applications, such as digital shelving in retail, factory storage, hospital medicine cabinets and others.

Advantech ePaper infrastructure is centrally managed and updated through the LEO-D Device Manager. The integrated back-end system can remotely transmit and receive data to and from the respective ePaper device. By providing a visual interface, monitoring of power, online/offline status, layout management and content preview, maintenance, and scheduling, LEO-D Device Manager delivers the flexibility to design and set up your very own customized use case.

Value and Highlights

  • Sunlight-readable display with 180-degree viewing angle
  • Supports data transmissions via BLE 5.0 / 2.4 GHz communication
  • Cableless design ensures quick installation
  • Battery supports operation for 5 years based on up to 4 updates per day
  • 3 Colors - black / white / red
  • Ultra-low power consumption provides long battery life
  • Low maintenance & Hardware cost
  • Wireless and compact design ensures rapid installation (within 3 seconds)
  • Flexible display fastener with diverse mount methods (lock with screws, stick/paste)
  • Each Access Point supports up to 5,000 LEO-D devices
  • LEO Device Manager to 20 Access Points and total 100,000 devices

Product Specs

  • LEO-D12 - 1.50" ePaper, BLE black / white / red
  • LEO-D22 2.10" ePaper, BLE black / white / red
  • LEO-D32 - 2.90" ePaper, BLE black / white / red
  • LEO-D52 - 5.65" ePaper, BLE black / white / red
  • LEO-D62 - 7.50" ePaper, BLE black / white / red
  • LEO-D82 - 11.60 ePaper, BLE black / white / red
  • LEO-D92 - 13.30" ePaper, BLE black / white / red
  • BLE 5.0 - 2.4 GHz, 802.11 ac/a/b/g/n, POE, Transmission rate 20m
  • LEO Server
  • LEO Device Manager S, supports up to 20 AP's

What to Learn More About LEO-D ePaper

Contact Us

LEO-D ePaper - INDUSTRIES

Smart Hospitals

SUB-1GHZ TECHNOLOGY FOR REAL-TIME CONTENT MANAGEMENT IN SMART HOSPITALS
Traditional paper-driven systems in hospital work and administration are fast becoming an idea of the past. Smart hospitals now leverage available technologies such as Advantech’s LEO-D ePaper system, so that hospital staff and management can reduce errors and save precious time otherwise spent filling out paperwork. With time saved using an ePaper system that unifies patient care information and promotes smooth healthcare workflow, healthcare staff can focus on providing quality care for patients, quickly and with relative ease.

For Doctors, Nurses and Other Patient-Facing Care Staff
  • Reduce staff workload: ePaper automatically synchronizes with the Hospital Information System (HIS).
  • Improve service efficiency to patients.

    For Pharmacists
  • Optimize drug inventory management in pharmacy.
  • Reduce operation errors in medicine picking and administering.
For Hospital Administrators & Management
  • Reduced total cost of ownership (TCO) savings
  • Increased consistency in information entry (medical nomenclature) and patient care workflow, thus reducing risks of malpractice.


Four Reasons to use Sub-1GHz in Hospitals

  • Roaming achieves flexible tag pairing for any workstation (such as a UD or rolling cart). Staffs may easily command fully synchronized patient care information. Received Signal Strength Indication (RSSI) technology is also employed to wirelessly determine asset location.
  • Strong propagation for hospital environments with obstructed conditions.
  • Superior over-reaching feature on a single hub for minimal hardware (gateway/hub) investment and simplified site development.
  • Ultra-low power consumption to manage data flow uses significantly less power and maintenance expenses for battery replacement

Smart Retail & Facilities

LEO-D BLE 5.0 ENABLES REAL-TIME PRICE CHANGES & SALES PROMOTIONS AND REDUCES ROLL-OUT TIME & LABOUR COSTS

Digital Shelving
  • Real-time price changes
  • Reduced preparation time and quick rollout of Sales
  • Promotions to all stores
  • Significant reduction of wrong price signages
  • Significant reduction of labour cost
  • Process Optimization for signages in stores
    • Warehouse
  • Streamline workflow by barcode scanning
  • Real-time inventory information (e.g. stock level, expiry date) synchronized with Warehouse Management System (WMS)
    • ID Card
  • Personal Identification of staff
  • Access Control
  • Visitor badge
    • Information Signage bathrooms
  • Toilet clean indicator
  • Information display in bathrooms
    • Instore Billboard
  • Advertising
  • Instore announcements
    • Meeting Room & Booking System
  • Meeting room status
  • Reservation information
    •

    Smart Office & Building

    SUB-1GHZ TECHNOLOGY AND BLE 5.0 IN SMART OFFICE AND BUILDING ENVIRONMENTS

    Meeting Room & Booking System
  • Meeting room status
  • Reservation information
    • ID Card
  • Personal Identification
  • Access Control
  • Visitor badge
    • Mobile Office Name card
  • Easy to book
  • Displaying name of booked office space
    • Billboard
  • Welfare and event advertising
  • Company policy announcements
  • Education information promotion
    • Information Signage bathrooms
  • Toilet clean indicator
  • Information display in bathrooms
    • Digital Shelving in coffee shop or canteen
  • Real-time information display of item name, price, nutrition facts etc.
    •

    Smart Factory / Warehouse

    ADVANCED SUB-1GHZ TECHNOLOGY ENABLES SMART FACTORY AND PROCESS OPTIMIZATION In today's smart manufacturing trend, process automation plays an important role in the factory. Intelligent display technology can reduce manual errors, increase productivity, improve manufacturing efficiency, and hence increase competitiveness in the industry. Advantech LEO-D e-paper solutions used in production line, inventory shelf will be able to display real-time information, optimize factory processes to achieve the goal of smart factory and smart warehouse.

    For Factory Operators
  • Streamline workflow by barcode scanning on production run cards
  • Real-time production status information display on the material carts
  • Indicate material cart location
    • For Material Pickers
  • Intelligent computer aided picking system (CAPS) with visualized tips and guidance
  • Real-time inventory information (e.g. stock level, expiry date) synchronized with Warehouse Management System (WMS)
    • For Factory Managers
  • Increase operating efficiency and productivity for labour expense savings
  • Clear information display synchronized with backend manufacturing system
    •

    Four Reasons to use Sub-1GHz in Factory and Warehouse

    • Roaming achieves flexible tag pairing for any workstation (such as a rolling material cart). Received Signal Strength Indication (RSSI) technology is also employed to wirelessly determine mobile cart location.
    • Strong propagation for factory and warehouse environments with obstructed conditions.
    • Superior over-reaching feature on a single hub for minimal hardware (gateway/hub) investment and simplified site development.
    • Ultra-low power consumption to manage data flow uses significantly less power and maintenance expenses for battery replacement
